LIQUID-COUPLED HEAT EXCHANGER ECONET
®
Installation & Maintenance Manual
18
FläktGroup DC_9010GB 20180327_R0 Specifications are subject to alteration without notice
EcoNet Parameters Settings Description
Default
O00 EcoNet v5.00 Welcom level
A00 OP INFO Operation status of EcoNet unit
A10 OP MODE Operation mode
A20 HEAT RECOV. 0-100% Heat recovery signal
A30 ACT.FLOWSETP l/s Actual flow setpoint
A40 LIQUID FLOW l/s Actual liquid flow
A50 SUP AIR FLOW l/s Supply air flow
A60 VALVE SETP. 0-100% Control valve setpoint
A70 VALVE POS. 0-100% Control valve position
A80 FREQ. CONV. 0-100% Frequency converter setpoint
A90 TEMP AT PUMP °C GT40 temperature at pump
AA0 FROST PROT T °C GT41 frost protection temperature
AA1 ICE PROT TEM °C GT42 ice protection temperature
B00 MENU Main menu
B10 FLOW CONTROL Flow control
B11 ACT.FLOWSETP l/s Actual flow setpoint
B12 LIQUID FLOW l/s Actual liquid flow
B20 OPER STATUS Operational status
B21 ECONET Econet control signals
B211 START ON/OFF Start command, digital input
B212 COOLING ON/OFF Cooling command, digital input
B213 COOL. RECOV ON/OFF Cooling recovery command, digital input
B214 HEAT RECOV 0-100% Heating recovery, analog input
B22 TEMPERATURES Temperature measurements
B221 TEMP AT PMP °C GT40 temperature at pump
B222 FROST PROT °C GT41 frost protection temperature
B223 ICE PROT T °C GT42 ice protection temperature
B23 FLOWS Measured flows and pressures
B231 LIQUID FLOW l/s Actual liquid flow
B232 SUP AIRFLOW m3/s Supply air flow
B233 LIQ D.PRESS kPa Liduid diff. pressure over supply air coil
B24 CONTROL SIGN Analog control signals
B241 VALVE SP. 0-100% Control valve setpoint
B242 VALVE POS. 0-100% Control valve position
B243 FREQ. CONV. 0-100% Frequency converter setpoint
B244 PUMP CTRL ON/OFF Pump control signal
B245 PUMP STATUS ON/OFF Pump status
B246 FUNCT.ALARM ON/OFF Functional alarm
B247 HARDW.ALARM ON/OFF Hardware olarm
