LIQUID-COUPLED HEAT EXCHANGER ECONET
®
Installation & Maintenance Manual
5
FläktGroup DC_9010GB 20180327_R0 Specifications are subject to alteration without notice
HEIGHT OF PIPE CONNECTION
eQ size H L W S E A PIPE SIZE
mm mm mm mm mm mm DN
005-027 880 625 700 680 730 630 25
032-045 1050 625 700 680 730 630 32
050-090 1075 930 950 900 950 850 50
108-158 1185 1075 1000 1075 1125 1025 65
180-216 1340 1073 1000 1090 1140 1040 80
L
S
E
W
200
H
A
GT42
SV40
GP40
GT40
GT41
GP41
Motor cable
2
3
4
1
6
5
DRAWING PUMP UNIT FOR EQ 005-014
L
S
E
W
200
H
A
GT42
SV40
GP40
GT40
GT41
GP41
Motor cable
2
3
4
1
6
5
STAZ-74
EQRZ-05
(Tillbehör)
Energy
Supply air
Tilluft, Tuloilma, Zuluft
Exhaust air
Frånluft Poistoilma, Abluft
1
3
2
5
4
6
Heating, Värme
Lämmitys, Wärme
Cooling, Kyla
Jäähdytys, Kälte
ECONET
®
2
3
4
5
6
1
Exhaust air Add. Energy Supply air
4A
5 1 6 2 3
Sketch: pump unit for eQ 005-014
