1 Product brief introduction
1.1 Summarize
Inverter
Technology
This device uses single tube IGBT inverter technology (the inverter frequency range is from
25-50KHz) to convert 50/60Hz alternating current (AC) to direct current (DC) and then to high
frequency and lower voltage rectification. The resulting pulse width modulation (PWM) output can
be used for the high-power DC power supply, Due to switching power inverter technology adopted,
the weight of the welder has been significantly decreased and the conversion efficiency of the whole
machine is increased by more than 30%.
Wide Voltage
Our cutting machine is equipped with a power supply voltage compensation device
，
The power
supply voltage will work when the rated voltage is within 15% of requirements. When using
extension cords, in order to reduce voltage drop, use a heavy duty extension cord (10 or 12AWG or
greater) or use the recommended configuration length.
Easy to Use Piloting arc system can strike arc easily with principle of high frequency oscillation .It has functions
that it can supply gas ahead and turn off gas delayed.High frequency arc starting
Widely Used It is suitable for cutting stainless ,Steel, alloy steel, mild steel, copper and other color metal
materials.
Superior
Performance
1.Stabilizing 2.Reliability 3.Lightness 4.Energy-saving and no noise 5.High cutting speed 6.Cutting
smoothly and no polish demands
Attention Plasma cutter, the consumables are not on correctly, they are usually missing the white spacer. Air
regular not on it the correct direction(this will not give it enough flow).
Air leaking from the hose connections. Customers don't know they have to touch the metal to start
the arc.
1.2 Technical parameters
TYPE FC500
Input power voltage (V) AC220
，
50/60Hz
Rated input current (A) 17.2
Rated power capacity (KVA) 5.2
Current adjustment range (A) 20-50
Cutting thickness (mm)
Carbon Steel≤16.0
Stainless Steel≤16.0
Aluminum≤6.0
Copper≤5.0
Voltage adjustment range (V) 90V-110V
No-load voltage (V) 260±20
Rated duty cycle 60%
Efficiency (%) 80%
Power factor 0.7
Protection class IP21S
Insulation class F
Size (mm) 490*290*340
Weight (Kg) 9.6
Mode Type A=High Frequency Plasma Cutter
