pressure), then Press down the pressure regulating knob;
(6) The scale position of the meter,suggest the indicated position is 60-70PSI(about 0.4Mpa) air pressure. When there is
too much water in the filter cylinder, the drain valve should be opened to drain the water.
2.2 Air compressor connect to plasma cutter
Air regulator is installed outside the machine Air regulator is installed inside the machine
2.3 Plasma Cutter Torch connect to machine
A=High Frequency Plasma
Cutter/PT31
B=No Touch Pilot Arc High Frequency
Plasma Cutter/AG60
C=Non Touch Pilot Arc Low
Frequency Plasma Cutter/IPT60
