SECTION 3
ASSEMBLING FUEL BED AND COMMISSIONING
3.1 ASSEMBLING THE CERAMICS AND FUEL BED
3.1.1 Place the fuel-bed front ceramic fibre as shown below in figure 11.
Fig. 11
3.1.2 Place the left hand and right hand front ceramic fibre pieces as shown
below in figure 12.
Fig. 12
18
NOTE : The position of the fuel-bed components are critical to the
performance of the product. Therefore please ensure that the fuel-bed
components are positioned as described in the following section prior to
requesting a service call due to soot build up, poor flame pattern etc.
Front ceramic fibre
Left and right hand front ceramic fibres
