IMPORTANT INFORMATION REGARDING FUELBED
POSITION ON COAL, PEBBLE & DRIFTWOOD MODELS.
d) Before continuing with the installation, ensure
that the fuelbed is located behind
the locating
tabs as shown below in Fig. 24, not on top of the
locating tabs as shown in Fig. 25
Fig. 24 - Shows correct
location of fuelbed
Fig. 25 - Shows incorrect
location of fuelbed
25
Fuelbed correctly
positioned behind
locating tabs
Fuelbed incorrectly
positioned on top of
the locating tabs
