The exact position and fit of the pebbles may be finely adjusted to give the
best appearance.
Warning : Use only the pebble set supplied with the fire. When replacing the
pebbles remove the old pebbles and discard them. Fit a complete
set of pebbles of the correct type. Do not fit additional pebbles or
any pebbles other than a genuine replacement set.
3.4 FITTING THE TRIM
Models supplied with three piece trim
a) Fit the 2 side pieces of the trim by overlapping the lips of the trim
over the side lips of the firebox, and securing with the magnets
provided
b) Fit the top piece of the trim by overlapping the lips of the trim over
the lips of the firebox and over the 2 side trims.
Models supplied with one piece trim
a) Fit the outer trim assembly to the firebox with the magnets
provided.
PEBBLE & DRIFTWOOD MODELS
a) Fit the outer trim assembly to the firebox with the magnets
provided. NB. The fret is a loose item and located beneath the trim
assembly.
3.5 FITTING THE FRET (COAL MODELS ONLY)
a) Remove the fret & ashpan cover from the packaging.
b) Place fret up to the front radiused section of the fuelbed, taking care
not to move coal positions.
c) Place ashpan cover under fret assembly and centralise.
NOTE : Some models in this range are not supplied with a fret from the
factory, therefore please consult your local retailer for fitting
advice on the type of fret supplied with these models.
26
