4.3 Removing the Control Tap from the fire.
4.3.1 Remove the burner assembly as in section 4.1.
4.3.2 Pull the control knob off the control tap spindle.
4.3.3 Loosen and remove the two gas pipe retaining nuts from the control
tap and release the ends of the gas pipes from the control tap body.
Remove the push in thermocouple from the end of the control tap.
4.3.4 Unscrew the control tap locknut from the front of the control panel and
remove the control tap.
4.3.5 To refit a control tap, reassemble in reverse order noting that the control
tap locates with a flat in the control panel. Carry out a gas tightness
test after re-assembly.
4.4 Removing the Thermocouple
4.4.1 Remove the burner assembly as in section 4.1
4.4.2 Remove the push in thermocouple from the end of the control tap and
and remove the thermocouple retaining nut from the mounting bracket
on the burner assembly.
4.4.3 Re-assemble in reverse order and carry out a gas tightness test.
PARTS SHORTLIST
Replacement of any other parts must be carried out by a competent person such
as a CORGI registered gas installer. The part numbers of the main replaceable
parts are as follows, these are available from your local Flavel Stockist, whose
details can be found on the CFM Europe website, in the “stockist” section.
Coal Pack B-67050 Coal Fuelbed Matrix B-67040
Pebble Pack B-68240 Pebble Fuelbed Matrix B-68230
L/H Fibre Board (Plain) B-67550 L/H Fibre Board (Brick Back) B-68170
R/H Fibre Board (Plain) B-67560 R/H Fibre Board (Brick Back) B-68160
Lower Fibre Board (Plain) B-67540 Lower Rear Fibre Board B-68150
Upp. Rear Fibre Board (Plain) B-67530 Upper Rear Fibre Board B-68140
Gas Valve B-67090 Driftwood Fuelbed Matrix B-81160
Burner Engine B-67890 Driftwood Pack B-81170
Ignition Wire B-67910
