5.4 ASSEMBLING THE FUEL-BED - Pebble Fuelbed Model
a) Place the fuelbed base centrally on to the fuelbed support and push
fully backwards to the rear face of the fibre boards Make sure that the
fuelbed base is located centrally in the fire box. See Fig. 29 below
Fig. 29
b) Position the front row of four large loose pebbles along behind the first
row of pebbles, ensuring that the flame paths as indicated are not
interupted. See Fig. 30 below
Fig. 30
36
Beige pebbles
to be positioned
as indicated
