c) Fit the three small pebbles onto the ribs in the fuelbed as
shown below, ensuring that the rear flame paths as indicated are
not interupted. See Fig. 31 below.
Fig. 31
The exact position and fit of the pebbles may be finely adjusted to give the
best appearance.
Warning : Use only the pebble set supplied with the fire. When replacing the
pebbles remove the old pebbles and discard them. Fit a complete
set of pebbles of the correct type. Do not fit additional pebbles or
any pebbles other than a genuine replacement set.
37
Beige pebbles to
be positioned as
indicated
