Fleck 2750 - Page 32

Printed in U.S.A.
Page 32
MODEL 2750 DOWNFLOW
Service Assemblies
60029 1600 Brine Valve
For Illustration, See Page 12
1 . . . . . 10249 . . . . . .Brine Valve Spring
1 . . . . . 10250 . . . . . .Retaining Ring
2 . . . . . 10329 . . . . . .3/8″ Brass Nu
2 . . . . . 10330 . . . . . .3/8″ Ferrule
2 . . . . . 10332 . . . . . .3/8″ Sleeve
1 . . . . . 11749 . . . . . .B/V Stem Guide
1 . . . . . 11982 . . . . . .O-Ring Brine Valve
1 . . . . . 12552 . . . . . .1600 Brine Valve Stem
1 . . . . . 12626 . . . . . .Shut-0ff Valve Seat
1 . . . . . 12748 . . . . . .Brine Valve Body
1 . . . . . 12550 . . . . . .Quad Ring
60034-XX 1700 Brine Valve,
Specify Refill Rate
For Illustration, See Page 11
1 . . . . . 10250 . . . . . .Brine Valve Spring
1 . . . . . 12550 . . . . . .Quad Ring
1 . . . . . 13201 . . . . . .Quad Ring
1 . . . . . 14785 . . . . . .Flow Control Retainer
1 . . . . . 14790 . . . . . .Brine Valve Body
1 . . . . . 14792 . . . . . .Brine Valve End Plug
1 . . . . . 14795 . . . . . .Brine Valve Piston
1 . . . . . 14797 . . . . . .Brine Valve Stem
1 . . . . . 14798 . . . . . .Spacer
2 . . . . . 14811 . . . . . .Piston Seal
1 . . . . . 15310 . . . . . .Brine Valve Spring
1 . . . . . 15517 . . . . . .Stem Guide
1 . . . . . 15414 . . . . . .Nut Ferrule 1/2″
1 . . . . . 16123 . . . . . .Nut 1/2″
1 . . . . . 16124 . . . . . .Ferrule 1/2″
60080-XX 1600 Injector Assembly,
Specify Injector Size
For Illustration, See Page 8
1 . . . . . 10227 . . . . . .Injector Screen
1 . . . . . 11893 . . . . . .Injector Cap
1 . . . . . 10229 . . . . . .Injector Cover Gasket
1 . . . . . 10328 . . . . . .90° Elbow 1/4″ NPT x 3/8″ Tube
2 . . . . . 10692 . . . . . .Screw
1 . . . . . 10913 . . . . . .Injector Nozzle
1 . . . . . 10914 . . . . . .Injector Throat
1 . . . . . 11475 . . . . . .Injector Body Gasket
1 . . . . . 17776 . . . . . .Injector Body
60381-XX 1700 Injector Assembly,
Specify Injector Size
For Illustration, See Page
8
1 . . . . . 11893 . . . . . . Injector Cap
1 . . . . . 10229 . . . . . . Injector Cover Gasket
1 . . . . . 17777 . . . . . . Injector Body
1 . . . . . 14801 . . . . . . Injector Nozzle
1 . . . . . 14802 . . . . . . Injector Throat
1 . . . . . 14803 . . . . . . Injector Screen
2 . . . . . 14804 . . . . . . Screw
1 . . . . . 14805 . . . . . . Injector Body Gasket
60090-HF 2750 Piston Assembly
For Illustration, See Page 8
1 . . . . . 10209 . . . . . . Quad Ring, -010
1 . . . . . 10234 . . . . . . O-Ring, -024
1 . . . . . 10598 . . . . . . End Plug Assembly
1 . . . . . 10909 . . . . . . Pin, Link
1 . . . . . 14451 . . . . . . Piston, 2750
1 . . . . . 14452 . . . . . . Piston Rod
60090-HF 2750 Piston Assembly
1 . . . . . 10598 . . . . . . End Plug Assy.
1 . . . . . 10909 . . . . . . Pin, Link
1 . . . . . 14451 . . . . . . Piston, 2750
1 . . . . . 14452 . . . . . . Piston Rod
60091-HF 2750 Piston Assy., Hot Water
1 . . . . . 10598-01 . . .End Plug Assy., Hot Water
1 . . . . . 14451 . . . . . . Piston 2750
1 . . . . . 14452 . . . . . . Piston Rod
1 . . . . . 10909 . . . . . . Pin, Link
60121 Seal & Spacer Kit, 2750
6 . . . . . 10545 . . . . . . Seal, Piston
1 . . . . . 10757 . . . . . . End Spacer
5 . . . . . 11451 . . . . . . Spacer,12 Hole
60122 Seal & Spacer Kit, 2750
Hot Water
6 . . . . . 10545 . . . . . . Seal, Piston
1 . . . . . 10757B. . . . . End Spacer
5 . . . . . 16589 . . . . . . Spacer, HW
