Fleck 2750 User Manual

Printed in U.S.A.
Page 4
MODEL 2750 DOWNFLOW
Water Conditioners Flow Diagrams
1 SERVICE POSITION
2 BACKWASH POSITION 3 BRINE POSITION
Hard water enters unit at valve inlet  flows thru piston  down
center tube
 thru bottom distributor and up thru the mineral 
around the piston and out the drain line.
Hard water enters unit at valve inlet
 flows up into injector
housing and down thru nozzle and orifice to draw brine from the
brine tank
 brine flows down thru mineral and enters the center
tube thru bottom distributor and out thru the drain line.
Hard water enters unit at valve inlet and flows down thru the mineral in the mineral tank.
Conditioned water enters center tube thru the bottom distributor
 then flows up thru the
center tube
 around the piston and out the top outlet of the valve.
FLOW CONTROL
BRINE VALVE
INLET
MINERAL TANK
BRINE TANK
BRINE VALVE
FLOW CONTROL
INLET
MINERAL
TANK
TANK
BRINE
BRINE VALVE
FLOW
CONTROL
INLET
MINERAL
TANK
BRINE
TANK
