Printed in U.S.A.
Page 9
MODEL 2750 DOWNFLOW
Control Valve
Parts List
Item No. Quantity Part No. Description
1 . . . . . . . . . 1 . . . . . . . . . . 14749 . . . . . . . . . . . . . Valve Body
2 . . . . . . . . . 6 . . . . . . . . . . 10545 . . . . . . . . . . . . . Seal
3 . . . . . . . . . 5 . . . . . . . . . . 11451 . . . . . . . . . . . . . Spacer
16589 . . . . . . . . . . . . . Spacer, Hot Water
4 . . . . . . . . . 1 . . . . . . . . . . 14451 . . . . . . . . . . . . . Piston
5 . . . . . . . . . 1 . . . . . . . . . . 14452 . . . . . . . . . . . . . Piston Rod
6 . . . . . . . . . 1 . . . . . . . . . . 10234 . . . . . . . . . . . . . O-Ring - End Plug
7 . . . . . . . . . 1 . . . . . . . . . . 10209 . . . . . . . . . . . . . Quad Ring - Piston Rod
8 . . . . . . . . . 1 . . . . . . . . . . 10598 . . . . . . . . . . . . . End Plug Assembly
10598-01 . . . . . . . . . . End Plug Assembly, Hot Water
9 . . . . . . . . . 1 . . . . . . . . . . 14805 . . . . . . . . . . . . . Injector Body Gasket
10. . . . . . . . . 1 . . . . . . . . . . 14802 . . . . . . . . . . . . . Injector Throat
11. . . . . . . . . 1 . . . . . . . . . . 17777 . . . . . . . . . . . . . Injector Body
12. . . . . . . . . 1 . . . . . . . . . . 14801 . . . . . . . . . . . . . Injector Nozzle
13. . . . . . . . . 1 . . . . . . . . . . 14803 . . . . . . . . . . . . . Injector Screen
14. . . . . . . . . 1 . . . . . . . . . . 10229 . . . . . . . . . . . . . Injector Cover Gasket
15. . . . . . . . . 1 . . . . . . . . . . 11893 . . . . . . . . . . . . . Injector Cover
10228 . . . . . . . . . . . . . Injector Cover, Hot Water
16. . . . . . . . . 2 . . . . . . . . . . 14804 . . . . . . . . . . . . . Screw - Injector Body
17. . . . . . . . . 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Washer - Flow Control (specify size)
18. . . . . . . . . 1 . . . . . . . . . . 15177 . . . . . . . . . . . . . Flow Control Housing
19. . . . . . . . . 2 . . . . . . . . . . 11710 . . . . . . . . . . . . . O-Ring Base
20. . . . . . . . . 1 . . . . . . . . . . 11208 . . . . . . . . . . . . . O-Ring Base
21. . . . . . . . . 1 . . . . . . . . . . 12461 . . . . . . . . . . . . . Adapter Base 2-1/2-8 Thd
22. . . . . . . . . 1 . . . . . . . . . . 10381 . . . . . . . . . . . . . O-Ring - Top of Tank
24. . . . . . . . . 2 . . . . . . . . . . 11224 . . . . . . . . . . . . . Screw - Valve Mounting
25. . . . . . . . . 1 . . . . . . . . . . 17776 . . . . . . . . . . . . . Injector Body
26. . . . . . . . . 1 . . . . . . . . . . 10914 . . . . . . . . . . . . . Injector Throat
27. . . . . . . . . 1 . . . . . . . . . . 10913 . . . . . . . . . . . . . Injector Nozzle
28. . . . . . . . . 1 . . . . . . . . . . 10227 . . . . . . . . . . . . . Injector Screen
29. . . . . . . . . 2 . . . . . . . . . . 10692 . . . . . . . . . . . . . Screw - Injector Body
30. . . . . . . . . 1 . . . . . . . . . . 10757 . . . . . . . . . . . . . End Spacer
10757B . . . . . . . . . . . . End Spacer, Hot Water
31. . . . . . . . . 1 . . . . . . . . . . 16221 . . . . . . . . . . . . . Air Disperser - 1600 Injector (not shown)
