MODEL 9000 ECONOMINDER

Service Assemblies
60022-25 . . . . . BLFC .25 GPM
60022-50 . . . . . BLFC .50 GPM
60022-100 . . . . BLFC 1.0 GPM
For Illustration, See Page 14
1 . . . . . . .12094 . . . . . . . . Flow Washer .25 GPM
12095 . . . . . . . . Flow Washer .50 GPM
12097 . . . . . . . . Flow Washer 1.0 GPM
1 . . . . . . .12977 . . . . . . . . O-Ring - 015
1 . . . . . . .13244 . . . . . . . . Adapter, BLFC
1 . . . . . . .13245 . . . . . . . . Retainer, BLFC Button
60350 . . . . . . . . Brine Valve Assy, 9000
For Illustration, See Page 14
1 . . . . . . .11973 . . . . . . . . Spring, Brine Valve
1 . . . . . . .11981 . . . . . . . . Retaining Ring
1 . . . . . . .16095 . . . . . . . . Washer, Plain #10 Nylon
1 . . . . . . .12550 . . . . . . . . Quad Ring, -009
1 . . . . . . .12626 . . . . . . . . Seat, Brine Valve
1 . . . . . . .13165 . . . . . . . . Cap, Brine Valve
1 . . . . . . .13167 . . . . . . . . Spacer, Brine Valve
2 . . . . . . .13302 . . . . . . . . O-Ring, -014
1 . . . . . . .14925 . . . . . . . . Brine Valve Stem, 9000
60385-XXXX. . . Injector/Drain Assy
See “Parts Price List”
60086 . . . . . . . . 3/4″ Meter, Standard Range
60087 . . . . . . . . 3/4″ Meter, Extended Range
For Illustration and Parts
See Page 19
6O389. . . . . . . . 1″ Meter, Standard Range
60390 . . . . . . . . 1″ Meter, Extended Range
For Illustration and Parts
See Page 18
60401 . . . . . . . . Piston Assy, 9000 Lower
For Illustration and Parts
See Page 14
1 . . . . . . .11335 . . . . . . . . Screw, Fil Hd
Mach 4-40 x 3/16
1 . . . . . . .13446 . . . . . . . . End Plug Assy White
1 . . . . . . .14309 . . . . . . . . Retainer, Piston Rod
1 . . . . . . .14905 . . . . . . . . Piston, Lower 9000
1 . . . . . . .14920 . . . . . . . . Piston Rod, Lower
1 . . . . . . .15019 . . . . . . . . Link, Piston Rod
60400. . . . . . . .Piston Assy, 9000 Upper
For Illustration, See Page 14
1 . . . . . . .11335. . . . . . . .Screw, Fil Hd
Mach 4-40 X 3/16
1 . . . . . . .13446. . . . . . . .End Plug, White Assy
1 . . . . . . .14309. . . . . . . .Retainer, Piston Rod
1 . . . . . . .14914. . . . . . . .Piston, Upper 9000
1 . . . . . . .14919. . . . . . . .Piston Rod, Upper
1 . . . . . . .14921. . . . . . . .Link, Piston Rod
60125. . . . . . . .Seal & Spacer Kit,
9000 - Upper
For Illustration, See Page 14
5 . . . . . . .13242. . . . . . . .Seal
4 . . . . . . .14241. . . . . . . .Spacer
60421. . . . . . . .Seal & Spacer Kit, 9000 -
Lower
For Illustration, See Page 14
11 . . . . . .13242. . . . . . . .Seal
8 . . . . . . .14241. . . . . . . .Spacer
1 . . . . . . .16595. . . . . . . .Spacer, 9000
60412. . . . . . . .9000 Powerhead Assembly
See “Parts Price List”
60375-XX. . . . .9000, Timer 1/15 RPM
60376-XX. . . . .9000, Timer 1/30 RPM
See “Parts Price List”
60136-9000 . . .9000 Service Repair Kit
See “Parts Price List”
DLFC, Flow Washers
12085. . . . . . . .Flow Washer, 1.2 GPM
12086. . . . . . . .Flow Washer, 1.5 GPM
12087. . . . . . . .Flow Washer, 2.0 GPM
12088. . . . . . . .Flow Washer, 2.4 GPM
12089. . . . . . . .Flow Washer, 3.0 GPM
12090. . . . . . . .Flow Washer, 3.5 GPM
12091. . . . . . . .Flow Washer, 4.0 GPM
12092. . . . . . . .Flow Washer, 5.0 GPM
12408. . . . . . . .Flow Washer, 7.0 GPM
