Storage
12-2
Long-Term Storage
(Over 60 Days)
1. Perform all steps as required for short-term
storage.
2. Run chassis engine to normal operat-
ing temperature. Operate automotive air
conditioner(s) to lubricate compressor
seals. Drain engine oil, replace lter, rell
engine with fresh oil.
3. Remove windshield wiper blades and store
inside the motor home.
4. Charge and remove both the chassis and
house battery(ies). Store in a cool, dry
place, and check the charge and water level
every 30 days. If the specic gravity is
being checked, recharge the battery when
it drops to 1.220. With the advent of com-
puter controlled engine and transmission
management systems certain procedures
must be followed whenever the chassis
battery is disconnected or replaced. Please
refer to your Chassis Operator’s/Owner’s
Guide/Manual for any instructions sup-
plied by the chassis manufacturer with
respect to this subject.
5. Remove, clean and replace roof air condi-
tioner lter(s). Cover the air conditioner
shroud(s).
6. To help preserve the tires, park each tire on
a piece of plywood about 12 inches square.
7. Cover the windows on the inside with foil,
cardboard, paper, etc., to reduce curtain,
drape, and carpet fading.
8. Remove batteries in battery-powered
devices.
9. During extended periods of storage, gaso-
line may deteriorate due to oxidation. This
can damage rubber and other materials in
the fuel system. It may also clog small ori-
ces. Commercially available gasoline fuel
stabilizers should be added whenever actual
or expected storage periods exceed 60 days.
Follow the additive manufacturer’s instruc-
tions. Operate the vehicle regularly during the
storage period to mix and circulate the anti-
oxidant agent throughout the fuel system.
10. Check tire ination pressures every 30
days. Maintain maximum rated cold ina-
tion pressure.
11. Check the sealant around all roof, oor and
body seams and windows. Reseal if neces-
sary. See Sealant Renewal section.
12. Lubricate all locks and hinges as described
in the Maintenance chapter.
13. Remove high grass or weed growth if
coach is parked on dirt.
WINTERIZATION
Thoughtful planning and preparation for the
winter season can help eliminate equipment fail-
ures and breakdowns, and can extend the life of
your motor home and its systems. Your dealer
can advise you concerning specic winterization
procedures and products for your climate area or
the areas through which you will be traveling.
Your dealer may also provide winterization ser-
vice for all appliances and systems in the motor
home. The following is a check list if you prefer
to perform these procedures yourself:
1. Check engine coolant level and antifreeze
protection. Drain and ush engine cooling
system and add antifreeze per the chassis
operator’s manual.
2. Service and winterize the generator as
outlined in the generator operating manual
included in your Owner’s Information
Package.
NOTE
If your motor home is equipped with a solar battery
charger, it will trickle charge the house battery. The
battery disconnect switch must be ON for the solar
charger to charge the batteries.
3
