Appliances
10-4
TELEPHONE JACK (If Equipped)
A telephone jack is conveniently located in the
front under the dash on the passenger’s side and
in various locations in the motor home. The park
connection point is located near the rear on the
roadside sidewall.
MICROWAVE OVEN (If Equipped)
The microwave oven is powered by 120-volt AC
power and will only operate when connected. A
wall receptacle for the microwave is located in the
overhead cabinet adjacent to the microwave cabinet.
WASHER/DRYER-READY
If an electric dryer is installed in the future by
either you, your dealer or another appliance
installer, the installation must comply with the fol-
lowing instructions:
1. The clothes dryer moisture-lint exhaust vent
duct must not be connected to any other
duct, vent, or chimney.
2. The exhaust duct must be of sufcient length
so as not to terminate beneath the recreation
vehicle.
3. The exhaust duct must not be connected with
sheet metal screws or other fasteners that
extend into the interior of the duct.
4. The exhaust duct and termination t-
tings must be installed in accordance
with the appliance manufacturer’s printed
instructions .
MISCELLANEOUS APPLIANCES
You may have additional appliances in your unit
which operate only when connected to 120-volt
power from either a public utility or the generator.
In 30 AMP systems, appliance selector switches
are provided in the galley to allow you to select
combinations of appliances yet still remain within
the power capacity of the electrical system.
TV Antenna Operation
WARNING
Do not raise antenna near overhead electric wires
as contact may cause serious injury.
!
