08-7
Electrical Systems
There is no programming necessary and the
unit will work with any load within the circuit
breaker limits. The Smart EMS automatically
“learns” the amount of current drawn by each of
the controlled loads as it turns them “ON” and
“OFF”. In this way, it automatically adapts to
differing loads or loads whose current changes
with line voltage or temperature.
Features:
• Energy Management of Generator source
and power (30/20) AMP.
• Minimizes circuit breaker tripping when
connected to Generator Source, 30 AMP or
20 AMP service.
• Eliminates manual appliance select
switches.
• Senses current of owner added loads.
• Owner selectable 20 AMP operation from
remote panel.
• Protects air conditioners with two minute
restart delay.
• “Learns” controlled appliance current
draw.
ELECTRICAL WIRING DIAGRAMS
Because of the many model, oor plans and
option variations available, it is beyond the
scope of this manual to include wiring dia-
grams. In certain situations, specic wiring
diagrams may be available to help troubleshoot
a problem. If you need specic wiring informa-
tion, please contact your dealer. Complete wir-
ing diagrams are not available.
MOTOR HOME FUSES AND
CIRCUIT BREAKERS
For information regarding fuses and circuit
breakers, please refer to the label afixed to
the individual circuit breaker fuse box(s).
NOTE
A troubleshooting guide and function manual that
explains this system is included with your motor home
Owner’s Infor mation Package.
3
