Page 7 of 18
Coolant System:
The coolant tank is located to right end of the machine looking from the front of the
machine. There is one motor and pump which is fixed to the coolant tank which
provides coolant to the machine. The capacity is:
175 Liters/46.25 gallons or 350 Liters/92.5 gallons
Chip Conveyor:
• A central auger removes chips that fall into bed and transports them to the chip
collector which is the top bin on the coolant tank.
PRECAUTIONS WHEN SELECTING THE PROPER COOLANT
Warning: There are several types of coolants available in the market. FlexCNC does not
recommend a given coolant. The user should select a coolant suitable for the intended
application, keeping in mind the following points:
• Operator Safety: coolant components shall neither be aggressive to the skin,
nor be harmful to people’s health (odor, poison, etc.).
• Coolant shall not suffer deterioration during its storage life.
• Coolant shall not cause corrosion to machine components.
• Coolant shall not deteriorate machine paint coating.
• Coolant shall not impair machine accuracy.
The frequency at which the coolant tank should be cleaned will depend on the coolant
used, type and material of the workpiece, etc. Consult coolant supplier for instructions.
Proper cleaning of the coolant and keeping coolant in good condition is of paramount
importance for both operator’s health and coolant performance.
Suction filters are standard for the entire range of spindle heads. It is located at the
motor-pump unit outlet and should be cleaned, depending on the type of material being
used, every month.
It should be noted that FlexCNC shall not be made responsible for any problem caused
by any improper use of coolant.
