14 Libraries FLUXUS F808, F809
UMFLUXUS_F808_8091V1-2-1EN, 2019-08-23 133
14.1.1 Data retention during the partitioning of the coefficient memory
When the coefficient memory is repartitioned, max. 8 data sets of each type can be retained.
14.2 Input of material/fluid parameters without extended library
In order to enter the material/fluid parameters as constants, the extended library has to be deactivated.
The parameters of a user defined material/fluid can be entered now.
The input of a material or a fluid is almost identical. Therefore, displays for a fluid will only be shown and described in case
of differences.
Material parameters
Fluid parameters
example 1: The number of user defined materials is reduced from 5 to 3. The data sets #01...#03 are retained.
The data sets #04 and #05 are deleted.
example 2: The number of user defined materials is increased from 5 to 6. All 5 data sets are kept.
Select Special Funct.\SYSTEM settings\Libraries\Extended Library. Press
ENTER.
Select off to deactivate the extended library. Press ENTER.
Select Special Funct.\Install Material or Install Medium. Press ENTER.
This error message will be displayed if the coefficient memory does not contain an area for
user defined materials/fluids.
Partition the coefficient memory accordingly (see section 14.1).
Select edit. Press ENTER.
Select a user defined material/fluid. Press ENTER.
Change the designation of the material/fluid.
The default name for a user defined material/fluid is USER MATERIAL N or USER MEDIUM
N with N being an integer.
Note!
There are 95 ASCII characters (letters, capital letters, numbers, special characters [!? " + - ( ) > < % *])
available for the designation of materials/fluids.
A designation can have max. 16 characters. The input of text is described in section 4.3.
Enter the sound speed of the material. Press ENTER.
For the sound speed of some materials annex C.1.
Enter the roughness of the material. Press ENTER.
For the typical roughness of some materials see annex C.2.
Enter the average sound speed of the fluid. Press ENTER.
Libraries ↕
Extended Library
Extended Library
>OFF< on
Special Funct. ↕
Install Material
USER Material
NOT FORMATTED !
Install Material
>EDIT< delete
USER Material ↕
#01:--not used--
EDIT TEXT (↑↓← →
USER MATERIAL 1
c-Material
1590.0 m/s
Roughness
0.4 mm
c-Medium
1500.0 m/s
