Flexispot EG1B-4024-EU - Specifications; Accessory Package; Parts Included; Diagram of Components

1
2
3
1
1
6
12
7
4
5
8
9
10
13
14
15
Accessory Package
Specifications Step 1:Install desk feet
01 02
Figures shown are for reference only. Please contact customer service if there are any accessory or
tools missing.
Attach the desk foot (5) to the lifting columns (3 & 4) using 8 M6 bolts (G) and 5x5 hex key (F).
Max. Weight Capacity
60 kg
Max. Speed
25mm/s
Input Voltage
10 0 - 240 V
Min. Height
730 mm
Max. Height
1230 mm
0 - 40 ℃
Duty Cycle
10% (Working 2 minutes then stop 18 minutes)
Working Temperature
Desktop Size
1000 mm in width
600 mm in depth
M6
C
X4
B
D
x2
X2
F
x4
x8
G
M8
2.5x2.5
ST4.2
M6
E
X14
ST4.8
Parts Included Diagram of Components
A
x2
M4
Wooden pin
x3
H
5x5
NO. Parts
Qty
1
1
1
2
1
1
1
8
5 6
11
12
1 2
7
3 4
9
10
13
14
15
1
1
1
2
1
1
4
1
NO. Parts
Qty
Desktop (small)
Desktop (large)
Lifting column Lifting column with motor
Desk foot Support plate
Crossbeam
Transmission rod
Baffle
Adapter
Adapter holder
Power cord
Keypad
Cable tie
Patch cord
G
x8
F
5 5x
5
3
4
F
G
