Maintenance
Created by EBCCW 00:06
17
5814EN-3
3 Remove the necessary number of
link
NB: With cleated or friction chains, pay
attention to the divisions between
the links.
4 Join the chain together with a new
pivot.
NB: The old pivot should not be re-
used. When the chain is divided, a
new pivot must always be fitted.
5 Insert the steel pin using the pin
insertion tool.
6 After inserting the steel pin, check
that it is centred and that the chain
easily bends in the fitted link
