Table of contents
1 General safety and design considerations 1
1.1 Introduction 1
2Safety 3
2.1 System information 3
2.2 Important safety conditions 3
3 Maintenance 7
3.1 System maintenance 7
3.2 Maintenance instructions 8
3.3 Introduction to drive units 9
3.4 Slip clutch adjustment 10
3.5 Inspection – drive units 12
3.6 Inspection – conveyor chains 14
3.7 Inspection – slide rails, beams, idlers, bends 18
3.8 Inspection – safety devices 20
3.9 Replacement of worn parts – conveyor chain 21
3.10 Replacement of worn parts – slide rails 22
4 Troubleshooting 26
4.1 Checklist/maintenance schedule 27
5 System dismantling and disposal 28
5.1 Important safety precautions 28
5.2 Dismantling end drive units with suspended
motor 29
5.3 Dismantling end drive units, no slip clutch 31
5.4 Dismantling end drive units, slip clutch 32
5.5 Remove guide rails and guide rail
brackets etc. 33
5.6 Remove the conveyor chain 34
5.7 Dismantling end drive units 35
5.8 Remove slide rails 36
5.9 Dismantle the conveyor extrusions from the
support brackets 37
5.10 Dismantle the conveyor support system 38
5.11 Disposing 39
5.12 Other equipment 39
