Page 3
© 2018 FlexRadio Sy
stems, V1.2
Preparing to In
stall the GP
SDO Module
The back panel plugs an
d
top
cover must be remo
ved before the GPSDO
can be installed.
Removing the Back-
Panel Metal Plugs
Place the FLEX-6000 on it
s feet with the b
ack facing you as
shown in t
he image below.
Using your fingernail or
an
other non-metal prying d
evice, remove the two (2
) metal plugs from th
e back
panel below the labels:
•
GPS ANT
•
10 MHz OUT
2
4
