FLIR A6 Series - Figure; Explanation

Example system overviews11
11.1.3 Figure
11.1.4 Explanation
1. Computer.
2. CAT-6 Ethernet cable with RJ45 connectors.
3. Industrial Ethernet switch.
4. FLIR A6xx cameras.
5. Industrial process to be monitored, e.g., a gasifier.
11.1.5 Figure
#T559950; r. AE/83475/83477; en-US
17
