2,87in
±0,00
73mm
±0,1
2,93in
±0,00
74,5mm
±0,1
9,44in
±0,04
239,9mm
±1
2,64in
±0,00
67mm
±0,1
2,32in
±0,04
59mm
±1
3,8
±0,04
96,5
±1
2,27in
57,8mm
2,55in
64,8mm
3,8in
96,5mm
Close-up lens
IR Lens f=24,6 mm
0,94in
24mm
1,08in
27,4mm
3,8in
96,5mm
Close-up lens
For additional dimensions see page 1
Camera with Close-up lens 5,8X (100 µm)
Sheet
Drawing No.
Size
Check
Drawn by
Denomination
A3
9(9)
T126925
Basic dimensions FLIR A/SC 6xx
CAHA
2012-04-18
R&D Thermography
Modified
1 2 3 4 5 6 7 8 9 10
A
B
C
D
E
F
G
H
1 32 54
C
F
B
D
G
E
A
6
Size
A
1:2
Scale
© 2012, FLIR Systems, Inc. All rights reserved worldwide. No part of this drawing may be reproduced, stored in a retrieval system, or transmitted in any form, or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without written permission from FLIR Systems, Inc. Specifications subject to change without further notice. Dimensional data is based on nominal values. Products may be subject to regional market considerations. License procedures may apply.
Product may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Diversion contrary to US law is prohibited.
-
