Example system overviews12

12.1.6 Explanation

1. Computer.

2. CAT-6 Ethernet cable with RJ45 connectors.

3. Industrial Ethernet switches with fiber optic ports.

4. Fiber-optic cable.

5. Wireless access points.

6. CAT-6 Ethernet cable with RJ45 connectors—powering the camera using PoE (de-

pendent on the camera model).

7. Industrial Ethernet switch.

8. FLIR A6xx cameras.

12.2 FLIR A6xx sc series

12.2.1 Figure

12.2.2 Explanation

1. Computer.

2. CAT-6 Ethernet cable with RJ45 connectors.

3. Laboratory set-up with a FLIR A6xx sc camera.

#T559950; r. AD/35720/35720; en-US
