FLIR A6 Series User Manual

Technical data14
Measurement analysis
Atmospheric transmission correction Automatic, based on inputs for distance, atmos-
pheric temperature and relative humidity
Optics transmission correction Automatic, based on signals from internal sensors
Emissivity correction Variable from 0.01 to 1.0
Reflected apparent temperature correction Automatic, based on input of reflected
temperature
External optics/windows correction Automatic, based on input of optics/window trans-
mission and temperature
Measurement corrections
Global object parameters
USB
USB
• Control and image
USB, standard USB 2 HS
USB, connector type
• USB Mini-B
USB, communication TCP/IP socket-based FLIR proprietary
USB, image streaming 16-bit 640 × 480 pixels @ 25 Hz
• Signal linear
• Temperature linear
• Radiometric
USB, protocols TCP, UDP, SNTP, RTSP, RTP, HTTP, ICMP, IGMP,
ftp, SMTP, SMB (CIFS), DHCP, MDNS (Bonjour),
uPnP
Ethernet
Ethernet Control and image
Ethernet, type
Gigabit Ethernet
Ethernet, standard IEEE 802.3
Ethernet, connector type RJ-45
Ethernet, communication
TCP/IP socket-based FLIR proprietary and GenI-
Cam protocol
Ethernet, image streaming 16-bit 640 × 480 pixels @ 50 Hz
16-bit 640 × 240 pixels @ 100 Hz
16-bit 640 × 120 pixels @ 200 Hz
• Signal linear
• Temperature linear
• Radiometric
GigE Vision and GenICam compatible
Ethernet, protocols TCP, UDP, SNTP, RTSP, RTP, HTTP, ICMP, IGMP,
ftp, SMTP, SMB (CIFS), DHCP, MDNS (Bonjour),
uPnP
Digital input/output
Digital input, purpose Image tag (start, stop, general), Image flow con-
trol, (stream on/off), Input ext. device (program-
matically read)
Digital input 2 opto-isolated, 0–1.5 V = low, 3–25 V = high
Digital output, purpose Output to ext. device (programmatically set)
Digital output 2 opto-isolated, ON = supply (max. 100 mA), OFF
= open
Digital I/O, isolation voltage 500 VRMS
#T559950; r. AD/35720/35720; en-US
31
