12mm
±0,1
(3x)
0,47in
±0,004
24mm
±0,1
(3x)
0,94in
±0,004
59mm
±1
2,32in
±0,04
203mm
±1
7,97in
±0,04
67mm
0
+
0,1
2,64in
0,000
+
0,004
36,9mm
1,45in
73mm
±0,1
2,87in
±0,004
36,5mm
1,44in
36,9mm
±0,1
1,45in
±0,004
74,5mm
±0,1
2,93in
±0,004
UNC 1/4-20 0,75xD Helicoil (3x)
M4 1xD Helicoil (6x)
1,32in
33,5mm
1in
25,5mm
FPA active area at
focus far (infinity)
Camera housing
Sheet
Drawing No.
Size
Check
Drawn by
Denomination
A3
1(9)
T126925
Basic dimensions FLIR A/SC 6xx
CAHA
2012-04-18
R&D Thermography
