5 Operation
6. One of the following results is displayed:
• 123 indicates clockwise or forward rotation, which means that the pre-
sumed phase line 1 is ahead of the presumed phase line 2.
• 321 indicates counterclockwise or reversed rotation, which means that
the presumed phase line 2 is ahead of the presumed phase line 1.
• - - - means that the meter is unable to determine the results.
• Lo V means that users possibly removed the test leads before completing
the testing procedure. To repeat the test, press the OK button again.
5.9 Resistance measurements
WARNING
Do not do diode, resistance, or continuity tests before you remove the power
from the capacitors and the other devices (when you do a test during a meas-
urement). Injury to persons can occur.
1. Set the function switch to the
position.
2. Ensure that the meter is set to resistance measurement. If the
or the
indicator is displayed, press the button repeatedly until none of these
indicators are displayed.
3. Insert the black probe lead into the negative COM terminal and the red probe
lead into the positive Ω terminal.
4. Touch the tips of the probe across the circuit or component under test.
5. Read the resistance value on the display.
5.10 Capacitance measurements
WARNING
Do not take capacitance measurements before you have removed the power
from the capacitor or other device or circuit during a test. Injury to persons can
occur.
