FLIR CM83 - Electrical Specifications

7 Technical specifications
CAT Application field
Ⅰ Circuits not connected to mains
Ⅱ Circuits directly connected to a low-
voltage installation
Ⅲ Building installation
Ⅳ Source of the low-voltage installation
Operating altitude: 2000 m (6562ʹ).
Jaw opening: 37 mm (1.45 in.).
Pollution degree: 2.
EMC: EN 61326-1.
Shock vibration: Random vibration per MIL-PRF-28800f Class 2 (5–55 Hz, 3g
maximum).
7.2 Electrical specifications
Accuracy is ±(% reading + number of digits (dgt)) at 23℃ ±5℃ (73.4℉ ±9℉),
<80% RH.
Table 7.1 Voltage (TRMS)
Function Range Accuracy (of reading)
1
DCV
99.99 V
±(0.7% + 2 dgt)
999.9 V
ACV
0.05–99.99 V ±(1.0% + 5 dgt)
999.9 V 50–500 Hz
VFD
ACV
0.05–99.99 V
50–60 Hz ± (1% + 5
dgt)
999.9 V
1. DCV <1000 dgt, add 6 dgt to the accuracy. ACV <1000 dgt, add 3 dgt to the accuracy.
Overload protection: 1000 V
rms
.
#T559825; r. AI/33557/33557; en-US 33
