Technical data27
Data communication interfaces
Interfaces USB 2.0, Bluetooth, Wi-Fi, DisplayPort
METERLiNK/Bluetooth Communication with headset and external sensors
Wi-Fi Peer to peer (ad hoc) or infrastructure (network)
Audio Microphone and speaker for voice annotation of
images
USB USB Type-C: data transfer/video/power
USB standard USB 2.0 High Speed
Video out DisplayPort
Video connector type DisplayPort over USB Type-C
Power system
Battery type Rechargeable Li-ion battery
Battery voltage 3.6 V
Battery operating time > 2.5 hours at 25°C (68°F) and typical use
Charging system In camera (AC adapter or 12 V from a vehicle) or
two-bay charger
Charging time (using two-bay charger)
2.5 hours to 90% capacity with charging status in-
dicated by LEDs
Charging temperature 0°C to +45°C (+32°F to +113°F), except for the Ko-
rean market: +10°C to +45°C (+50°F to +113°F)
External power operation
AC adapter 90–260 V AC, 50/60 Hz, or 12 V from a
vehicle (cable with standard plug—optional)
Power management Automatic shut-down and sleep mode
Environmental data
Operating temperature range –15 to +50°C (5–122°F)
Storage temperature range –40 to +70°C (–40 to +158°F)
Humidity (operating and storage) IEC 60068-2-30/24 hours/95% relative humidity
25–40°C (77–104°F)/two cycles
EMC
• ETSI EN 301 489-1 (radio)
• ETSI EN 301 489-17
• EN 61000-6-2 (immunity)
• EN 61000-6-3 (emission)
• FCC 47 CFR Part 15 Class B (emission)
Radio spectrum
• ETSI EN 300 328
• FCC Part 15.249
• RSS-247 Issue 2
Encapsulation IP 54 (IEC 60529)
Shock 25g (IEC 60068-2-27)
Vibration 2g (IEC 60068-2-6)
Drop Designed for 2 m (6.6 ft.)
Safety EN/UL/CSA/PSE 60950-1
Physical data
Weight (including battery) 1 kg (2.2 lb.)
Size (L × W × H) 278.4 × 116.1 × 113.1 mm (11.0 × 4.6 × 4.4 in.)
#T810190; r. AL/47698/47698; en-US
117
