FLIR E53

Working with measurement tools
16
16.1 General
To measure a temperature, you can use one or more measurement tools, e.g., a spotmeter
or a box.
16.2 Adding/removing measurement tools
Follow this procedure:
1. Push the navigation pad to display the menu system.
2. Select
(Measurement) and push the navigation pad. This displays a submenu.
3. Use the navigation pad to select one of the following:
• Select
(No measurements) to remove all tools.
• Select
(Center spot) to add a center spot.
• Select
(Hot spot) to add a hot spot detection within a box area.
• Select
(Cold spot) to add a cold spot detection within a box area.
• Select (depending on the camera model)
(User preset 1) to add user preset 1
or
(3 spots) to add three spots.
• Select (depending on the camera model)
(User preset 2) to add user preset 2
or
(Hot spot - Spot) to add a hot spot and a spot and display the temperature
difference.
4. Push the navigation pad to confirm and exit the menu mode.
