FLIR M364 User Manual

Inspectingthethermalcamera
Routinelyinspectthecameraanditsmountingsurfacetoensurethatitisinstalledsecurely,
thatthecoatedsurfacesareintact,andthattherearenosignsofcorrosion.
Whenthecameraispoweredoff,graspitrmlyatthebaseandconrmitisrigidand
secure.Thenholdthecameraabovethebaseandconrmitwillrotatefreelyandwithout
noticeablewobbleorloosenessaroundthepanbearing.
Wateringress
Wateringressdisclaimer
Althoughthewaterproofratingcapacityofthisproductmeetsthestatedstandard(referto
theproduct’sTechnicalSpecication),waterintrusionandsubsequentequipmentfailuremay
occuriftheproductissubjectedtocommercialhigh-pressurewashing.FLIRwillnotwarrant
productssubjectedtohigh-pressurewashing.
Disclaimer
FLIRdoesnotwarrantthatthisproductiserror-freeorthatitiscompatiblewithproducts
manufacturedbyanypersonorentityotherthanFLIR.
FLIRisnotresponsiblefordamagesorinjuriescausedbyyouruseorinabilitytousethe
product,bytheinteractionoftheproductwithproductsmanufacturedbyothers,orbyerrors
ininformationutilizedbytheproductsuppliedbythirdparties.
EMCinstallationguidelines
FLIRequipmentandaccessoriesconformtotheappropriateElectromagneticCompatibility
(EMC)regulations,tominimizeelectromagneticinterferencebetweenequipmentandminimize
theeffectsuchinterferencecouldhaveontheperformanceofyoursystem
CorrectinstallationisrequiredtoensurethatEMCperformanceisnotcompromised.
Note:InareasofextremeEMCinterference,someslightinterferencemaybenoticedon
theproduct.Wherethisoccurstheproductandthesourceoftheinterferenceshouldbe
separatedbyagreaterdistance.
ForoptimumEMCperformancewerecommendthatwhereverpossible:
•FLIRequipmentandcablesconnectedtoitare:
–Atleast1m(3ft)fromanyequipmenttransmittingorcablescarryingradiosignalse.g.
VHFradios,cablesandantennas.InthecaseofSSBradios,thedistanceshouldbe
increasedto7ft(2m).
–Morethan2m(7ft)fromthepathofaradarbeam.Aradarbeamcannormallybe
assumedtospread20degreesaboveandbelowtheradiatingelement.
•Theproductissuppliedfromaseparatebatteryfromthatusedforenginestart.Thisis
importanttopreventerraticbehavioranddatalosswhichcanoccuriftheenginestart
doesnothaveaseparatebattery.
•FLIRspeciedcablesareused.
•Cablesarenotcutorextended,unlessdoingsoisdetailedintheinstallationmanual.
Note:Whereconstraintsontheinstallationpreventanyoftheabove
recommendations,alwaysensurethemaximumpossibleseparationbetweendifferentitems
ofelectricalequipment,toprovidethebestconditionsforEMCperformancethroughout
theinstallation
Importantinformation
11

FLIR M364 Specifications

General

Image Processing	FLIR Proprietary Digital Detail Enhancement
Pan/Tilt	360° Continuous Pan, +/- 90° Tilt
Resolution	640 x 480
Field of View	24° x 18°
Video Output	HD-SDI
Power	24 VDC
Environmental	IP66
Weight	11 lbs (5 kg)
