ORION SC7000 User Manual
DCOO5U-F ORION SC7000 User Manual Page 10
NB: Configuration #3 is dedicated to harsh environments. It comes with the following
extension module for:
ON / OFF button
RS232 command
Analog Video
Trigger OUT connector
Connection to Camera
IRIG-B connector
Power IN connector
Trigger IN connector
Trigger/Genlock selector
Genlock IN connector
