FLIR Ranger R Series - 1 Introduction; Equipment Features and Specifications; Table 1 - R1, R2, R3, R3 D, R5 and R5 D Radar Assembly Specifications

910-0001-00-INS -R02 Page 10 of 53
Information contained in this document pertains to a Canadian origin product that is controlled as "dual use" by the Canadian
government. However, when in the United States or possessed by a US person, it may be considered a defense article from the US Government's
perspective. US government authorization may be required for re-transfer to a foreign person. If you have any questions, please contact FLIR's
Global Trade Compliance group at exportquestions@flir.com .
1 INTRODUCTION
This manual describes the R1, R2, R3, R3D, R5 and R5D Perimeter Surveillance Radars (PSR) installation
and scheduled maintenance actions. Complete electrical, mechanical and physical interfaces of the
system are also provided. The Installation manual is intended for an audience of technically qualified
personnel.
Note
For detailed instructions on how to use the different modes of the
R1, R2, R3, R3D, R5 and R5D,
please refer to the Operator Manual for Mid-Range Perimeter Surveillance Radars.
1.1 EQUIPMENT FEATURES AND SPECIFICATIONS
1.1.1 R1, R2, R3, R3D, R5 and R5D Radar Assembly
The R1, R2, R3, R3D, R5 and R5D provide detection capability for moving objects on the ground over an
area of up to 360° and presents detection data to the operator through a Graphical User Interface
(GUI). The data may also be transmitted via a third-party software application using an Extensible
Markup Language (XML) Client responsible for implementing security policies.
R1, R2, R3 and R3D Specifications R5 and R5D Specifications
Weight R1, R2, R3: 12.5 Kg R3D: 13.2 Kg 17 Kg
Cooling No forced cooling required
Operating
Temperature Range
-30ºC to +60ºC
Operating Altitude
Range
Up to 15,000 ft. / 4,572 m.
Power Input 20 - 32 VDC (Nominal 24 VDC ), less than 45 W
Frequency Band Ka
Instrumented Range
R1: 5- 700 m R2: 5-1400 m
R3: 5-2800 m R3D: 5-6500 m
R5: 10-5000 m R5D: 5-10000 m
Warm-up time Ready to operate approximately 1 minute after power-up
Scan rate Up to 55 scans/minute
Environmental NEMA 4, IP65
Wind
140 Km/hr
Radiated Power
Safe for human exposure
Table 1 – R1, R2, R3, R3D, R5 and R5D Radar Assembly Specifications
