910-0001-00-INS -R02 Page 48 of 53
Information contained in this document pertains to a Canadian origin product that is controlled as "dual use" by the Canadian
government. However, when in the United States or possessed by a US person, it may be considered a defense article from the US Government's
perspective. US government authorization may be required for re-transfer to a foreign person. If you have any questions, please contact FLIR's
Global Trade Compliance group at exportquestions@flir.com .
7.3 CLEANING THE UNIT
Follow the instructions below to clean the Assembly:
Step 1 Use a moist clean cloth if the radome is lightly soiled.
Step 2 Use a mild cleaner and moist cloth if the radome is heavily soiled.
7.4 EXTERNAL MECHANICAL INSPECTION
Follow the instructions below to perform an external mechanical inspection:
Step 1 Inspect for cracks, damage or deterioration.
Note
maged part, contact FLIR Radars
Customer Support for repair instructions.
7.5 REMOVING THE RADOME
Follow the instructions below to remove the Radar Radome:
Step 1 Set the radome on a clean surface and with a moist clean cloth wipe the surface of any dirt.
Step 2 Remove the radome by first unscrewing the 8 screws under the base of the unit. Refer to
Figure 28 to see the location of the screws.
Step 3 Carefully remove any dirt on the radome and gasket. Pay particular attention to locations
where these parts are in contact with each other. Replace gasket if damaged. Contact FLIR
Radars Customer Support for to help in ordering a new one.
Figure 28 – Radome screws location
