Camera parts
10
9. Image archive button .
Function:
• Push to open the image archive.
• Push and hold for more than 2 seconds to perform a manual calibration.
10. Touch-screen LCD.
11. Power indicator.
12. On/off button
.
Function:
• Push and release to turn on the camera.
• Push and hold for more than 0.5 second to turn off the camera.
10.5 Neck strap attachment points
10.5.1 Figure
10.6 Battery condition LED indicator
10.6.1 Figure
10.6.2 Explanation
Type of signal Explanation
The green LED flashes twice per second. The battery is being charged.
The green LED glows continuously. The battery is fully charged.
#T559954; r. AP/42311/42335; en-US
22
