FLIR T1040 User Manual

Annotating images19
19.4.2 Procedure
Follow this procedure:
1. Open the image in the image archive.
2. Push the joystick. This displays a context menu.
3. Select
(Add voice annotation) and push the joystick.
4. To start a recording, select
(Record) and push the joystick.
5. To stop the recording, select
(Stop) and push the joystick.
6. To listen to the recording, select
(Play) and push the joystick.
7. To delete the recording, select
(Delete) and push the joystick.
8. When completed, select
(Done) and push the joystick.
19.5 Adding a sketch
19.5.1 General
You can add a freehand drawing to an image.
19.5.2 Procedure
Follow this procedure:
1. Open the image in the image archive.
2. Push the joystick. This displays a context menu.
3. Select
(Add sketch) and push the joystick.
4. You are now in sketch mode. Draw the sketch by touching the screen.
#T559954; r. AP/42311/42335; en-US
71
