Handling the camera13
13.4 Turning on and turning off the camera
• To turn on the camera, push and release the On/Off button.
• To turn off the camera, push and release the On/Off button.
13.5 Adjusting the angle of lens
13.5.1 Figure
13.5.2 Procedure
To adjust the angle, tilt the lens up or down.
13.6 Adjusting the infrared camera focus
13.6.1 Procedure
To adjust the infrared camera focus, do one of the following:
• Push the focus button left for far focus.
• Push the focus button right for near focus.
• Push the Autofocus/save button halfway down to autofocus the camera.
Note
It is important that you hold the camera steady while autofocusing.
13.7 Mounting an additional lens
Note
Do not touch the lens surface when you mount an infrared lens. If this happens, clean the lens accord-
ing to the instructions in 28.2 Infrared lens, page 67.
#T559879; r. AG/12171/13006; en-US
24
