FLIR T4 Series User Manual

Handling the camera13
4. Push the rear part of the sunshield toward the screen, and then release your grip.
Make sure that the two tabs mate with the corresponding notches.
13.10 Using the laser pointer
13.10.1 Figure
13.10.2 Procedure
Follow this procedure:
1. To turn on the laser pointer, push and hold the laser pointer button.
2. To turn off the laser pointer, release the laser pointer button.
Note
The laser pointer may not be enabled in all markets.
Note
The symbol
is displayed on the screen when the laser pointer is on.
13.11 Calibrating the compass
13.11.1 Procedure
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
(Settings).
3. Push the joystick to display the Settings menu.
4. Select Device settings and push the joystick.
5. Select Compass and push the joystick.
#T559879; r. AG/12171/13006; en-US
29
