Handling
the
camera
13
6.
Rot
ate
the
lens
cap
30°
clockwise
(looking
at
the
front
of
the
lens).
13.9
Attaching
the
sunshield
13.9.1
Procedure
Follow
this
procedure:
1.
Align
the
two
front
tabs
of
the
sunshield
with
the
corresponding
two
notches
at
the
top
of
the
screen.
2.
Push
the
front
part
of
the
sunshield
into
position.
Make
sure
that
the
two
tabs
mate
with
the
corresponding
notches.
3.
Carefully
hold
together
the
two
rear
wings
of
the
sunshield.
#T559879;
r.
AG/12171/13006;
en-US
28
39
41
