Working with measurement tools16
16.7 Setting a measurement alarm
16.7.1 General
You can make the camera trigger an alarm when certain measurement conditions are
met.
16.7.2 Types of alarm
You can choose between the following alarm types:
• Above: Triggers an alarm when the temperature is above the preset alarm
temperature.
• Below: Triggers an alarm when the temperature is below the preset alarm
temperature.
16.7.3 Alarm signals
When an alarm is set, the symbol
is displayed in the result table.
When an alarm is triggered, the value in the result table is displayed in red and the sym-
bol
is blinking.
You can also set an audible alarm (there will be a ‘beep’ when the alarm is triggered).
16.7.4 Procedure
The procedures for setting up an alarm for a spot is different from setting up an alarm for
a box, circle, or line.
16.7.4.1 Setting up an alarm for a spot
Follow this procedure:
1. To select the spot, touch the tool on the screen. The tool is now displayed with a
frame.
2. Push the joystick. This displays a context menu.
3. Use the joystick to go to
(Set alarm on spot).
4. Push the joystick. This displays a dialog box where you can define the settings for the
alarm.
• Alarm condition: The condition that triggers the alarm. Applicable values are
above, below, or off.
• Alarm limit: The temperature value that will be the critical condition when an alarm
is triggered or not.
• Alarm sound: Applicable values are beep or no sound.
5. Push the joystick. This closes the dialog box.
6. Push the joystick and select
(Done).
16.7.4.2 Setting up an alarm for a box, circle, or line
Note
• This procedure assumes that you have previously set the camera to display at least one value (max-
imum, minimum, or average) in the result table.
Follow this procedure:
1. To select the measurement tool, touch the tool on the screen. The tool is now dis-
played with one or more handles.
2. Push the joystick. This displays a context menu.
3. Use the joystick to go to (depending on tool)
, , or (Max/Min/Avg/Alarm)
or (Graph/Max/Min/Avg/Alarm).
#T559879; r. AG/12171/13006; en-US
43
