Technical data24
Measurement
Object temperature range
• –20°C to +120°C (–4°F to +248°F)
• 0°C to +650°C (+32°F to +1202°F)
Accuracy
• ±1°C (±1.8°F) or ±1% of reading for limited
temperature range.
• ±2°C (±3.6°F) or 2%, whichever is greater, at
25°C (77°F) nominal.
Measurement analysis
Spotmeter
5
Area 5 areas (boxes or circles) with max./min./average
Profile 1 line profile with max/min temp.
Automatic hot/cold detection
Auto hot or cold spotmeter markers within area
and profile
Measurement presets No measurements, Center spot, Hot spot, Cold
spot, User preset 1, User preset 2
User presets The user can select and combine measurements
from any number of spots/boxes/circles/profiles/
delta
Difference temperature Delta temperature between measurement func-
tions or reference temperature
Reference temperature Manually set using difference temperature
Emissivity correction Variable from 0.01 to 1.0 or selected from materi-
als list
Measurement corrections Emissivity, reflected temperature, relative humid-
ity, atmospheric temperature, object distance, ex-
ternal IR window compensation
Colors (palettes) Iron, Rainbow, Rainbow HC, White hot, Black hot,
Arctic, Lava
Alarm
Color Alarm (isotherm) Above/below/interval
Measurement function alarm Audible/visual alarms (above/below) on any se-
lected measurement function
Screening Difference temperature alarm, audible
Set-up
Set-up commands Define user presets, Save options, Programmable
button, Reset options, Set up camera, Wi-Fi,
Compass, Bluetooth, Language, Time & units,
Camera information
Service functions
Camera software update Use PC software FLIR Tools
Storage of images
Image storage
Standard JPEG, including digital photo and meas-
urement data, on memory card
Image storage mode
• Simultaneous storage of thermal and digital
photo in same JPEG file.
• Optional to store digital photo as a separate
JPEG file.
Time lapse 15 seconds to 24 hours
#T559879; r. AH/23788/24627; en-US
