0.98in
25mm
4.7in
119.4mm
5.51in
140mm
1.52in
38.5mm
6.41in
162.8mm
6.47in
164.34mm
UNC ¼” -20
Optical axis
2.7in
68.7mm
1.43in
36.2mm
1.89in
47.9mm
Optical axis
0.98in
25mm
1.89in
47.9mm
4.7in
119.4mm
5.49in
139.3mm
1.42in
36mm
1.89in
47.93mm
1.42in
36.1mm
Optical axis
0.41in
10.5mm
Camera housing
Sheet
Drawing No.
Size
Check
Drawn by
Denomination
A3
1(4)
T129914
Basic dimensions FLIR T8xx
JOHE
2020-01-14
R&D Instruments
Modified
1 2 3 4 5 6 7 8 9 10
A
B
C
D
E
F
G
H
1 32 54
C
F
B
D
G
E
A
6
Rev
C
1:2
Scale
