Handling
the
camera
7
4.
Remo
ve
the
hand
strap
from
the
bracket
at
the
base
of
the
camera.
5.
Put
the
new
hand
strap
into
the
bracket
at
the
base
of
the
camera.
6.
Push
the
bracket
into
the
camera.
Make
sure
that
the
two
holes
in
the
hand
strap
are
aligned
with
the
holes
in
the
bracket.
7.
Tighten
the
two
T6
screws.
8.
Thread
the
loose
strap
through
the
upper
attachment
point.
Secure
the
strap
with
the
hook-and-loop
fastener
.
#T810413;
r.
AF/83467/83910;
en-US
38
44
46
