7 Technical specifications
7.1 System specifications
Dimensions 29 mm × 26 mm × 156 mm(1.1″ ×
1.0″ × 6.1″)
Weight 0.20 kg (0.44 lb), including batteries
Battery life 7 hours continuous with the work light
off
Battery type 2 × AAA (LR03)
Agency approvals CE, UL/cUL
FLIR VP50 excitation voltage 90 V AC minimum
FLIR VP52 excitation voltage 190 V AC minimum
Voltage ranges 90 to 1000 V (FLIR VP50)
190 to 1000 V (FLIR VP52)
24 to 1000 V in high sensitivity mode
(FLIR VP50 and FLIR VP52)
Detection distance 0 to 5 cm
Category rating CAT IV-1000 V
Frequency range 45 - 65 Hz
Built-in work light Yes
Vibrating indication Yes
Off switch Yes
7.2 Environmental specifications
Operating temperature 0℃ to 60℃ (–32℉ to 140℉ )
Storage temperature –40℃ to 90℃ (–40℉ to 194℉)
#T559851; r. AG/ 10041/10041; en-US 12
