FLOWROX PV 80 - Page 14

12
Fig. 10.1.
Fig. 10.2.
Fig. 10.3.
DIMENSION X [mm]
Fig. 11.
VALVE SIZE
(mm)
PRESSURE CLASS (Bar)
1 6…10 16…25
25…100 1.5 2.5 3.5
125…250 2.0 3.0 4.0
300…500 3.0 4.0
550… 4.0
