Suction
Discharge
16FRBH244
8200
4200
6100
11570
9650
7560
7320
3660
5420
8450
6670
10230
(6050)
(3100)
(4500)
(2600)
(2170)
(1700)
(5400)
(2700)
(4000)
(1900)
(1500)
(2300)
18FRBH274
8200
4200
6100
11570
9650
7560
8200
4200
6100
9610
7560
11570
(6050)
(3100)
(4500)
(2600)
(2170)
(1700)
(6050)
(3100)
(4500)
(2160)
(1700)
(2600)
20FRBH304
9080
4750
6780
12900
10720
8450
9080
4750
6780
10760
8450
12900
(6700)
(3500)
(5000)
(2900)
(2410)
(1900)
(6700)
(3500)
(5000)
(2420)
(1900)
(2900)
24FRBH304
10850
5830
8130
15480
13120
10230
10850
5830
8130
13080
10230
15660
(8000)
(4300)
(6000)
(3480)
(2950)
(2300)
(8000)
(4300)
(6000)
(2940)
(2300)
(3520)
Notes:
1) F = External force (tension or compression) M = External
moment, clockwise or counter-clockwise
2) Forces and moments may be applied simultaneously in any
direction
3) Values apply to all materials
4) Higher loads may be applicable, if direction and magnitude of
individual loads are known, but these need written approval from
Flowserve
5) Pumps must be on rigid foundations and baseplates must be
fully grouted
6) Pump/baseplate should not used as pipe anchor. Expansion
joints must be properly tied
7) The pump mounting bolt torques specified must be used to
prevent relative movement between the pump casing and
baseplate. (See section 6.6, Fastener torques.) The bolt material
must have a minimum yield strength of 600 N/mm
2
(87 000 lb/in.
2
)
