15.6 Positioner Performance
Characteristics
Table 14: Performance Characteristics
Better than or equal to the following values on a 25 square inch
Mark I actuator.
Resolution
 0.25%
Linearity
+/-0.8%
Repeatability
 0. 05%
Hysteresis
 1.0%
Deadband
 0. 1%
Sensitivity
 0.25%
Stability
 0.4%
Long term drift
 0.5%
Supply Pressure Effect
 0.2% per 10 psi (0.69 bar)
 NOTE: Performance tested according to ISA 75.13.
15.7 Temperature
Table 15: Temperature
Operating Temperature
Range
-55 to 85°C (-67 to 185°F)
Transport and Storage
Range
-55 to 85°C (-67 to 185°F)
 NOTE: Reduced performance possible at low and high
temperatures. LCD may not be readable at temperatures
below -20°C (-4°F) and temperatures above 70°C (158°F).
15.8 Physical Specifications
Table 16: Physical Specifications
Housing Material
Cast, powder-painted Copper-free
aluminum (EN AC-43400/EN AC-
AlSi10Mg(Fe))
Cast, stainless steel (A-743-CN7M (ALLOY
20))
Soft Goods
Fluorosilicone / Fluorocarbon / Buna-N
Weight of Base
Positioner Without
Accessories
4 kg (8.8 lbs.) – Aluminum
8 kg (17.6 lbs.) – Stainless Steel (Alloy 20)
15.9 ValveSight DTM Software
Specifications
Table 17: ValveSight DTM Software Specifications
Computer
Minimum Pentium processor running
Windows 2000, XP, Server 2003, Server
2003 R2, Server 2008 (32-bit & 64-bit
Versions), Server 2008 R2 (32-bit & 64-bit
Versions), and 7 (32-bit & 64-bit Versions).
Memory: >64MB Available HARD Disk
Space : >64MB
Ports
One minimum available with eight
maximum possible. (Can also
communicate via serial, and USB
connections)
HART Filter
Often required in conjunction with some
DCS hardware.
