APPENDIX A – LCD MENU TREE OVERVIEW
LOGIX 3800zb MAIN MENU
1. Status
Command (mA)
Command (%)
Position (%)
Temperature
Valve Cycles
Valve Travel
Analog Output (AO)
Analog Input (AI)
Discrete Input (DI)
2. Alerts and Alarms
Current Alarms
Event History
Back
Home
3. Partial Stroke Test
Start
Last Result
Back
Home
4. Step Test
Start
Step Size XX%
Back
Home
5. Calibration
Stroke/Quick Calibration
Command Input Calibration
Calibration Dates
Back
Home
6. Configuration
6.1 Positioner Tuning
Open Stroke Time
Close Stroke Time
Open Speed Limit
Close Speed Limit
Back
Home
(Edit Register)
6.3 Limits
Soft Limit High
Soft Limit Low
Tight Shutoff High
Tight Shutoff Low
Position High Alert
Position Low Alert
Position Deviation
Back
Home
6.4 Positioner Feedback
Remote Mount
Back
Home
6.5 Date & Time
6.6 User Preferences
All Units
Temperature Units
Actuator Area Units
Date Format
Number Format
Back
Home
6.7 Burst Mode
ON/OFF
Back
Home
6.8 Positioner Revs
SW Rev
Build Date
Build Time
HW Rev
HART Version
Back
Home
6.9 Factory Reset
7. Auxiliary I/O
7.1 AO
Set 0%
Set 100%
Back
Home
7.3 DI
No Function
Start PST
Cmd Override
Set Cmd Point
Config. energize/de-energize
Back
Home
7.2 AI
Set 0%
Set 100%
Back
Home
8. Language
English
German
French
Spanish
Portuguese
Russian
Italian
Back
Home
9. Display
Contrast
Backlight
LCD Orientation
LCD Scroll Data
Back
Home
6.2 Characterization
MaxFlo Linear
MaxFlo Equal %
Valdisk Linear
Valdisk Equal %
ShearStream Linear
ShearStream Equal %
Custom
Back
Home
